Best Price of TJC 5 Inch HMI Touchscreen LCD Display in Pakistan | X5 Series TJC8048X550 AI Smart Resistive Touch Display
Multifunctional HMI Display Module with Serial Port USART
What is the Price of TJC 5 inch HMI LCD in Pakistan today?
You can now purchase this TJC 5 inch display (X5 Series) for best prices at TechonicsLtd.com, the International Supplier of Industrial Automaton Products.
Basic Parameters of TJC8048X550 011R
| parameter | data | Description |
| colour | 65K(65536)color | 16-bit Color palette 5R6G5B |
| Dimensions | 136.9(L)×84(W)×5.8(H) | TJC8048X550_011R |
| Display size | 120.7mm(L)×75.8mm(W) | 800×480 Pixel mode |
| Visual size (AA) | 108mm(L)×64.8mm(W) | 800×480 Pixel mode |
| Resolution | 800×480 Pixel | Can be set to 480×800 |
| Touch type | 4 Wire precision resistance type | |
| Number of touches | least 100 Million times | |
| Backlight mode | led | |
| Backlight life (average) | >30,000 hour | |
| brightness | 300nit | Can proceed 100 Level brightness adjustment |
| Net Weight | 130g |
Electrical performance parameters of 5 inch TJC HMI (X5 Series)
| parameter | Test Conditions | Minimum | Typical value | Max | unit |
| Operating Voltage | 4.65 | 5 | 6.5 | V | |
| Working current | VCC=+5V, The maximum backlight brightness | – | 350 | – | mA |
| SLEEP mode | 170 | mA | |||
| Recommended power supply:5V 1A DC power supply | |||||
Working environment and reliability parameters of Taojingchi 5 inch HMI LCD
| parameter | test environment | Minimum | Typical value | Max | unit |
| Operating temperature | 5V Under voltage, humidity 60% | -20 | 25 | 70 | °C |
| Storage temperature | – | -30 | 25 | 85 | °C |
| Working humidity | 25°C | 10% | 60% | 90% | RH |
| Three prevention treatment | – | – | no | – | – |
Interface performance parameters
| Parameter | Test Conditions | Minimum | Typical value | Max | unit |
| Serial output level (TXD) | Output 1,Iout=1mA | 3.0 | 3.2 | – | V |
| Output 0,Iout=-1mA | – | 0.1 | 0.2 | V | |
| Serial input level (RXD) | Output 1,Iout=1mA | 2.0 | 3.3 | 5.0 | V |
| Output 0,Iout=-1mA | -0.7 | 0.0 | 1.3 | V | |
| Interface level | 3.3V/5V TTL Level(or 232 Level) | ||||
| Communication mode | 8,1,None | ||||
| User interface mode | 4Pin_2.54mm With lock | ||||
| SD Card interface | Have(FAT32 File format) maximum support 32G Micro TF/SD card | ||||
| Expand IO | 8 Road extension IO IO0-IO7 Support input and output, control binding events,IO6-IO7 stand by PWM | ||||
| RTC | Have RTC | ||||
Memory characteristics of TJC 5.0” X5 series
| Memory category | parameter | Minimum | Typical value | Max | unit |
| FLASH Memory | Font image storage space | 120 | MB | ||
| User store | EEPROM | 1024 | BYTE | ||
| Running memory(RAM) | Control/Variable storage space | 512 | KB | ||
| Serial command buffer | Serial command buffer | 1024 | BYTE |
Audio characteristics of TJC Chinese HMI LCD (TJC8048X550_011R) (optional)
| Speaker characteristics | parameter | Minimum | Typical value | Max | unit |
| power | 16 ohm 0.5W | 0.5 | W | ||
| Dimensions | Φ40 X 5.2H | mm | |||
