LCD Display Module
GLT240128-WB (LCD Graphic RS 232 BLU/WHT)
Full touch screen, no keypad needed! Our Graphic LCD Touch Panel provides you with a cost effective user interface solution for that great product/project you are developing. On board memory for Fonts and Bitmaps! This touch screen graphic LCD displays graphics and text in any font, style, justification and language, all with the convenience of a touch screen.The Serial LCD Controller combines a 240 x 128 graphic LCD display a resistive touch screen, so you can get started creating powerful, simple user interfaces.
HMI Smart LCD screen 2.2 inch 320 x 240 (TJC3224T022_011N)
Model : TJC3224T022_011N Touch mode : NO-Touch HMI smart screen function leads to the RX and TX TTL level microcontroller , can not be directly connected to the computer RS232 , must be through the conversion chip level , such as the MAX232 chip . or direct purchase of USB to TTL level line converter.
MI0283QT-9A (2.8″ TFT Color Display with Resistive Touch Screen)
Nextion 3.5″ Display NX4832T035 Generic- Resistive Touch Screen UART HMI LCD Module
- NX4832T035 is nextion 3.5 basic screen: 3.5 inch TFT, 480x320 resistive touch display, 16M flash, 2K Byte RAM, 65k colors.
- You can power nextion 3.5 from 5V pin of microcontroller but not recommended. Working with insufficient power may damage the screen, so pls use the power board came with nextion. See the image on how to use it.
- Uploading TFT file via sd card is faster than 4pin serial port, but pls check card is FAT32 format and no more than 32GB.
Nextion 4.3″ NX4827K043 Enhanced HMI Intelligent Smart USART UART Serial Touch TFT LCD Module for Raspberry Pi
Features
Support built-in RTC
Support GPIO
SD Card interface: support max max 32G Micro TF/SD card (FAT32 file format)
Flash data storage space: 32MB
EEPROM: 1024 byte
RAM: 3584 byte
Instruction buffer: 1024 byte
Color: 65K (65536) colors
Resolution: 480×272 pixel
Adjustable Brightness:0~180 nit, the interval of adjustment is 1%
NEXTION 7.0”- Intelligent Series NX8048P070-011R | HMI IPS RGB 65K Resistive Touchscreen Display Module
Introduction:
Nextion is a Human Machine Interface （HMI） solution combining an onboard processor and memory touch display with Nextion Editor software for HMI GUI project development.Using the Nextion Editor software, you can quickly develop the HMI GUI by drag-and-drop components (graphics, text, button, slider, etc.) and ASCII text-based instructions for coding how components interact at display side.
Nextion HMI display connects to peripheral MCU via TTL Serial (5V, TX, RX, GND) to provide event notifications that peripheral MCU can act on, the peripheral MCU can easily update progress and status back to Nextion display utilizing simple ASCII text-based instructions.
Hardware Features:
- NX8048P070-011R(7.0'' IPS RGB 65K Resistive touchscreen)
- Onboard MCU 200MHz and up to 128MB for the HMI project
- Built-in RTC，EEPROM, 8 digital GPIOs (2 PWM capable).
- 4 pins (+5V, TX, RX, GND) TTL serial interface.
- 300 nit Brightness with 1% interval adjustment.
- Audio interface.
- Recommended Power Supply: 5V, 2A, DC
- CE and RoHS Compliant.
- Model: NX8048P070-011R((HMI Resistive Touch Display).
Nextion Enhanced NX4832K035 3.5 Inch HMI Intelligent Smart USART UART Serial Touch Screen TFT LCD Module
General Features:
- Supports built-in RTC
- Supports GPIO
- SD Card interface: support max 32G Micro TF/SD card (FAT32 file format)
- Flash data storage space: 32MB
- EEPROM: 1024 bytes
- RAM: 8192 bytes
- Instruction buffer: 1024 bytes
- Color: 65K (65536) colors
- Resolution: 480×320 pixel
- Adjustable Brightness:0~180 nit- the interval of adjustment is 1%
Nextion NX4827T043 4.3 Inch HMI Intelligent Smart USART UART Serial Touch TFT LCD Screen Module
General Introduction:
- NX4827T043 is nextion 4.3 basic screen: 4.3 inch TFT, 480x272 resistive touch display, 16M Flash, 2K Byte RAM, 65k colors.
- You can power nextion 4.3 from 5V pin of microcontroller but not recommended. Working with insufficient power may damage the screen, so please use the power board came with nextion. See the image on how to use it.
- Uploading TFT file via sd card is faster than 4pin serial port, but pls check card format is FAT32 and no more than 32GB.
Nextion NX4832F035 3.5” Discovery Series HMI Resistive Touch Display Module
Introduction:
NX4832F035 is a Nextion Discovery series 3.5” capacitive HMI touchscreen.• 3.5″ LCD-TFT HMI Display • STM32GO ARM® Cortex®-M0+ 64MHz Onboard MCU Processor • Fonts Creator with Versatile Character Encodings • Low Learning Curve Text-based Instruction Set • Support 15+ Amazing WYSIWYG Components • New Nextion Cost-effective HMI Solution
Nextion NX8048T070 – Basic Series 7.0″ HMI TFT LCD Resistive Touch Display
Introduction:
Nextion is a Human Machine Interface （HMI） solution combining an onboard processor and memory touch display with Nextion Editor software for HMI GUI project development.Using the Nextion Editor software, you can quickly develop the HMI GUI by drag-and-drop components (graphics, text, button, slider, etc.) and ASCII text-based instructions for coding how components interact at display side.
Nextion HMI display connects to peripheral MCU via TTL Serial (5V, TX, RX, GND) to provide event notifications that peripheral MCU can act on, the peripheral MCU can easily update progress and status back to Nextion display utilizing simple ASCII text-based instructions.
Features:
- Compatible with Raspberry Pi A+, B+, Pi 2, Pi 3, Arduino
- 800 x 480 Resolution
- RGB 65K true to life colors
- TFT Screen with integrated 4-wire Resistive Touch Panel
- 4 pin TTL serial interface
- 16M Flash memory for User Application Code and Data
- Onboard micro-SD card slot for firmware upgradation
- Visual Area: 154.08mm(L)×85.92mm(W)
- Adjustable Brightness: 0~230 nit, the interval of adjustment is 1%
- Recommended Power Supply: 5V, 2A, DC
- Certificates: CE/EMC, RoHS (certificates)
Nextion-Intelligent Series- NX4827P043 4.3 Inch HMI Intelligent USART UART Serial Touch TFT LCD Screen Module without Enclosure
Overview:
- Nextion- Intelligent Series (P)
- 4.3” LCD-TFT HMI display module
- 480 x 272 screen resolution
- RGB 65K true-to-life colors
- Resistive touch panel
- 300 nit Brightness
- Onboard 200MHz MCU
- 512 KB of SRAM
- 128 MB of Flash memory
- 1024 Byte EEPROM
- XH2.54 4 Pins (+5V, TX, RX, GND) TTL serial interface
- 1.25T-2-2A Audio port for external speaker connection
- 8 Digital extended GPIO
- (IO0-IO7 support input, output, and component binding event, IO6-IO7 support PWM)
Built-in RTC support Note: This information is obtained from Nextion's official website for transparency. Explore further details at: [https://www.nextion.tech]
