Best Price of TJC 10.1 Inch HMI Touchscreen LCD Display in Pakistan | X5 Series TJC1060X5A1_011C_Y AI Smart Capacitive Touch Display
Multifunctional TFT HMI 10.1 inch Display Module with Serial Port UART
What is the Price of TJC 10.1 inch HMI LCD (TJC1060X5A1_011C_Y) in Pakistan today?
You can now purchase this TJC 10.1 inch Capacitive display (X5 Series) for best prices from Techonics LTD, the wholesaler of TJC and Nextion in Pakistan.
Technical Specifications of TJC 10.1 Inch HMI Touchscreen:
Basic parameter of TJC1060X5A1_011C_Y
| Parameter | Data | Description |
| Color | 65K (65536) color | 16-bit palette 5R6G5B |
| Dimensions | 258(L)×152(W)×11.5(H) | TJC1060X5A1_011C_Y |
| Display size | 235mm(L)×143mm(W) | 1024×600 pixel mode |
| Visual size (AA) | 222.72mm(L)×125.28mm(W) | 1024×600 pixel mode |
| Resolution | 1024×600 pixels | Can be set to 600×1024 |
| Touch-type | Capacitive | |
| Number of touches | At least 1 million times | |
| Backlight mode | led | |
| Backlight life (average) | >30,000 hours | |
| brightness | 300nit | 100 levels of brightness adjustment possible |
| Net Weight | 505g | |
| RTC | YES | |
Electrical performance parameters of TJC 10 Inch HMI LCD (X5 Series)
| Parameter | Test Conditions | Minimum | Typical Value | Max | unit | |
| Operating Voltage | 4.65 | 5 | 6.5 | V | ||
| Working current | VCC=+5V, maximum backlight brightness | – | 800 | – | mA | |
| SLEEP mode | 170 | mA | ||||
| Recommended power supply: 5V 2A DC power supply | ||||||
Working environment and reliability parameters of TJC 10.1 Inch HMI Display
| Parameter | Test environment | Minimum | Typical Value | Max | unit |
| Operating temperature | Under 5V voltage, humidity 60% | -20 | 25 | 70 | °C |
| Storage temperature | – | -30 | 25 | 85 | °C |
| Working Humidity | 25℃ | 10% | 60% | 90% | RH |
| Three prevention treatment | – | – | no | – | – |
Interface Performance Parameters: TJC 10.1 inch Industrial HMI Display (X5)
| parameter | Test Conditions | Minimum | Typical value | Max | unit |
| Serial port baud rate | standard | 2400 | 9600 | 921600 | bps |
| Serial output level (TXD) | Output 1, Iout=1mA | 3.0 | 3.2 | – | V |
| Output 0, Iout=-1mA | – | 0.1 | 0.2 | V | |
| Serial input level (RXD) | Output 1, Iout=1mA | 2.0 | 3.3 | 5.0 | V |
| Output 0, Iout=-1mA | -0.7 | 0.0 | 1.3 | V | |
| Interface level | 3.3V/5V TTL level (or 232 level) | ||||
| Communication mode | 8,1,None | ||||
| User interface mode | 4Pin_2.54mm with lock | ||||
| SD card interface | Yes (FAT32 file format) Maximum support 32G MicroTF/SD card | ||||
| Extended IO | 8-channel expansion IO
IO0-IO7 supports input and output, control binding events, IO6-IO7 supports PWM |
||||
Audio characteristics (Optional)
| Speaker characteristics | parameter | Minimum | Typical value | Max | unit |
| power | 16 ohm 0.5W | 0.5 | W | ||
|
Dimensions |
Φ40 X 5.2H | mm |
Memory characteristics: TJC 10.1 inch Capacitive Touchscreen HMI (X5)
| Memory category | Parameter | Minimum | Typical value | Max | unit |
| FLASH memory | Font image storage space | 120 | MB | ||
| User store | EEPROM | 1024 | BYTE | ||
| Run memory (RAM) | Control/variable storage space | 512 | KB | ||
| Serial command buffer | Serial command buffer | 1024 | BYTE |
Techonicsltd, Pakistan’s no 1 wholesaler for HMI, HDMI LCDs, sensors, dev boards and moreover Mobile, Laptop, Tablet panel LCDs, and Other Spare Parts at wholesale prices! Get the best prices in Pakistan. Contact us now!
