PIC18F66K80 is a high performance 8-bit MCU with Integrated ECAN™ featuring eXtreme Low Power consumption. New features in PIC18F66K80 include low sleep current for low power application, 1.8V to 5.5V operating voltage for automotive, building control, elevator control and industrial application, Timers/Enhanced Compare/Capture/PWMs for precision timing control, 12-bit ADC for advance analog interface and Charge Time Measurement Unit for easy capacitive touch user interface. The PIC18F66K80 family is ideal for applications requiring cost-effective, low-power CAN solutions with high performance and robust peripheral set.

Featuring nanoWatt XLP Technology ideal for battery applications
• • 20 nA Sleep mode (Watch Webinar)
  • 300nA Watch Dog Timer operation in Sleep modes
  • Integrated ECAN™ conforming to CAN 2.0B active specification
  • Extreme Low Power Sleep mode ideal for battery applications
  • Operating voltage 1.8V – 5.5V
  • Charge Time Measurement Unit (CTMU) supports Touch sensing and advanced sensing applications
  • 11 ch, 12-bit ADC
  • 4 Capture / Compare / PWM modules and 1 Enhanced Capture / Compare / PWM modules
  • 1 MSSP serial ports for SPI or I2C™ communication
  • 2 Enhanced USART modules
  • Two analog comparators
  • Digital Signal Modulator
  • Self programming Flash supports 10k erase/write cycles & 20 years retention

General Parametrics:

Program Memory Type: Flash

Program Memory Size (KB): 64

CPU Speed (MIPS/DMIPS): 16

SRAM Bytes: 3,648

Data EEPROM/HEF (bytes): 1024

Digital Communication Peripherals: 2-UART, 1-SPI, 1-I2C1-MSSP(SPI/I2C)

Capture/Compare/PWM Peripherals: 5 Input Capture, 4 CCP, 1 ECCP,

Timers: 2 x 8-bit, 3 x 16-bit

ADC Input: 11 ch, 12-bit

Number of Comparators: 2

Number of CAN Modules: 1 CAN

Temperature Range (C): -40 to 125

Operating Voltage Range (V): 1.8 to 5.5

Pin Count: 64

Low Power: Yes
